DMON CPF350 IP67 Waterproof Linear LED Strobe Light (32+16 Segments)
The Dmon CPF350 is an IP67-rated waterproof LED strobe light with 32 independently controllable RGB segments and 16 independently controllable white segments, combining 672 RGB LEDs with 112 white LEDs. With 16-bit smooth linear dimming and DMX512/RDM control, the CPF350 delivers detailed segmented effects built for the most demanding outdoor waterproof conditions.
- IP67 waterproof — the highest level of water and dust protection for sustained outdoor exposure
- 32+16 independently controllable segments — detailed chase and pattern effects across color and white layers
- Multiple DMX channel modes (6 CH to 116 CH) — flexible integration with different console setups
- RDM support — remote monitoring and status checks from the console
We offer comprehensive after-sales services, including installation guidance and technical support. Our products also come with a specified warranty period to ensure a worry-free experience for our customers.
Function Description
Most outdoor fixtures top out at IP65 or IP66, protecting against rain but not standing water or submersion. The CPF350's IP67 rating gives it a wider safety margin for installations near fountains, pools, or areas prone to flooding.
A single-layer strobe array limits how a chase effect can look. The CPF350 separates 32 RGB segments from 16 white segments, giving designers two independently controllable layers to build more complex effects than a single-array fixture allows.
Application Scenarios
Specification
| LED Configuration | 672 × 0.3W SMD 5050 RGB LEDs; 112 × 3W SMD 3030 White LEDs | Input Voltage | AC 100–240V, 50/60Hz |
| Power Consumption | 350W | Control Modes | DMX512, Auto, Master-Slave, Sound Active, RDM |
| DMX Channels | CH06 / CH14 / CH16 / CH20 / CH32 / CH38 / CH64 / CH67 / CH69 / CH112 / CH116 | Dimming | 16-bit smooth linear dimming 0–100% |
| Strobe Frequency | 1–30 Hz | Segment Structure | 32 RGB segments + 16 White segments |
| Operating Temperature | -30°C to +50°C | Housing | Metal housing, black finish |
| Connection | DMX512 input/output, Power input/output | IP Rating | IP67 waterproof |
Details & Features
Frequently Asked Questions
What does the IP67 rating mean compared to lower ratings?
IP67 offers protection against dust and temporary immersion, going beyond the rain protection of IP65-rated fixtures — suited for installations near water features or areas prone to flooding.
Can the CPF350 be controlled by third-party lighting consoles?
Yes. It runs on standard DMX512 protocol with multiple selectable channel modes (6 CH up to 116 CH), and supports bi-directional RDM, compatible with any DMX/RDM-compliant console on the market.
What's the difference between the RGB segments and the white segments?
The 32 RGB segments handle the color output, while the 16 white segments run as a separate, independently controllable layer — allowing designers to combine or contrast white flashes with colored effects.
Does the LED source need to be replaced like a traditional lamp?
No. The CPF350 uses LEDs with no scheduled lamp replacement cycle required under normal use, unlike traditional discharge-lamp fixtures.
Do you offer OEM/ODM or custom branding?
Yes. We support OEM/ODM services including custom logo, packaging, and configuration for bulk orders. Contact us for MOQ details.
What's the warranty and how does after-sales support work?
2-year warranty with 3-business-day response commitment. Parts are supplied at cost price, and we guarantee parts availability for 5 years after any model is discontinued.
