DMON LM470S 470W LED CMY Spot & Beam Hybrid Moving Head Light
The Dmon LM470S is a 470W LED CMY spot & beam hybrid moving head light powered by a 400W high-brightness LED module rated for approximately 50,000 hours. With linear CMY+CTO color mixing, dual gobo wheels, and 3°–35° zoom, the LM470S delivers versatile projection effects, while its modular structure keeps maintenance straightforward for long-term use.
- 50,000-hour LED engine — long service life with minimal maintenance downtime
- Linear CMY + CTO color mixing — continuous color and temperature control beyond fixed wheels
- Dual gobo wheels (9 rotating + 10 static) + detachable gobos — extensive pattern variation, easy to replace
- Modular structure — designed for easy servicing and reduced maintenance time
We offer comprehensive after-sales services, including installation guidance and technical support. Our products also come with a specified warranty period to ensure a worry-free experience for our customers.
Function Description
Field servicing a moving head usually means disassembling the whole unit to reach one part. The LM470S is built with a modular structure, so individual components can be accessed and serviced without tearing down the entire fixture — cutting down repair time for your maintenance team.
A fixed color wheel forces hard jumps between preset colors. The LM470S's linear CMY+CTO system handles continuous color mixing and adjustable color temperature in one pass, giving designers smoother transitions than a standard color wheel allows.
Application Scenarios
Specification
| Light Source | 400W High-Brightness LED Module | LED Lifetime | Approx. 50,000 hours |
| Input Voltage | AC 100–240V, 50/60Hz | Power Consumption | 500W @ 220V |
| Power Factor | PF > 0.9 | Color Temperature | 7500K (native) + linear CTO |
| Zoom Angle | 3°–35° | Dimming | 0–100% linear electronic dimming |
| Strobe | 0.3–25 Hz | Color Wheel | 13 colors + open |
| Color Mixing | CMY color mixing + linear CTO adjustment | Rotating Gobo Wheel | 9 gobos + open (detachable for easy replacement) |
| Static Gobo Wheel | 10 gobos + open + 4 beam effects | Prism | 6-facet prism |
| Frost | Independent frost lens for soft output | Focus | DMX linear focus, ultra-smooth adjustment |
| Pan / Tilt | 540° / 270° with automatic repositioning | Motor System | Three-phase stepping motors, fast and quiet |
| DMX Channel Modes | 34 / 39 CH | Control Protocol | DMX512 |
| Cooling | Intelligent silent fan with LED temperature display | Maintenance | Modular structure for easy servicing |
| Operating Temperature | Up to 50°C ambient | IP Rating | IP20 |
| Net Weight | 24.25 kg | Gross Weight | 29.5 kg |
| Packing Size | 500 × 345 × 835 mm (L×W×H) |
Details & Features
What's in the Box
- • DMON LM470S Moving Head (400W LED Module)
- • Signal Cable
- • Power Cable
- • Omega Clamp
- • User Manual
Flight case available as an optional accessory.
Frequently Asked Questions
Can the LM470S be controlled by third-party lighting consoles?
Yes. It runs on standard DMX512 protocol with selectable 34 CH or 39 CH modes, compatible with any DMX-compliant console on the market.
Does the LED source need to be replaced like a traditional lamp?
No. The LM470S uses a 400W high-brightness LED module rated for approximately 50,000 hours, significantly longer than a traditional discharge lamp, with no scheduled lamp replacement required under normal use.
What does the modular structure mean for maintenance?
Key components are designed to be accessed and replaced individually, rather than requiring a full teardown of the fixture — reducing repair time when servicing is needed.
Are the gobos easy to replace?
Yes. The rotating gobo wheel uses detachable gobos, allowing quick replacement without disassembling the gobo wheel itself.
Do you offer OEM/ODM or custom branding?
Yes. We support OEM/ODM services including custom logo, packaging, and configuration for bulk orders. Contact us for MOQ details.
What's the warranty and how does after-sales support work?
2-year warranty with 3-business-day response commitment. Parts are supplied at cost price, and we guarantee parts availability for 5 years after any model is discontinued.
